EcoFlow PowerPulse 2 EV-Charger 22 kW
The prices are only visible to business customers and are only displayed after successful registration.
| AC phases | 1, 3 |
|---|---|
| Ladeleistung | 22 kW |
| Packaging unit in pieces | 1 pc. |
| Product Warranty | 3 Jahre |
| Use Case | Private |
| Intelligent charging | Yes |
| Connector Type | Socket |
| Charging Points | 1 |
Specification see current data sheet.
Price for full pallets on request.
Price for larger quantities on request –inquire now.
Product Benefits
- Charging power up to 22 kW (1- or 3-phase, configurable)
- Smart Charging with PV integration and AI-driven energy management
- App and web portal for monitoring and remote access
- Comprehensive protection features including RCD, surge and overcurrent protection
- Connectivity via WiFi, Bluetooth, RS485, CAN; OCPP 1.6-J compatible
- Flexible use indoors and outdoors (IP55)
- Charging cable not included, available separately
Introduction
The EcoFlow PowerPulse 2 is an intelligent wallbox with up to 22 kW charging power, supporting both single-phase and three-phase operation. It is suitable for private and commercial charging applications and stands out with integrated Smart Charging and photovoltaic support. Connected to the EcoFlow ecosystem, it provides users with an energy-optimized, safe, and convenient charging experience.
Functions & Installation
The PowerPulse 2 offers various charging modes such as fast charging, scheduled charging, individual profiles, and PV-based charging options. Through the EcoFlow App or web portal, charging sessions can be monitored and controlled, while RFID and Bluetooth ensure simple user authentication. With WiFi, RS485, CAN, and OCPP 1.6-J, the wallbox is ready for integration into smart energy management systems.
For installers, the device offers flexible connection options up to 10 mm² cable cross-section and simple wall mounting. With Protection Class I, IP55 protection, integrated RCD Type A + 6 mA DC detection, and further safety features such as surge and short-circuit protection, the PowerPulse 2 meets the highest standards. It can be used indoors and outdoors at temperatures from -30 °C to +50 °C. Note: The charging cable is not included and must be ordered separately.
Manufacturer
EcoFlow is one of the innovative providers in the field of energy and charging infrastructure. Focusing on sustainable solutions, EcoFlow develops products designed for seamless integration into modern energy systems.
Find more information about the brand on our manufacturer page.
